CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-109
3.1.5 Directional protection activation information (ACD)
ACD class (Directional protection activation information)
gePhsACD
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
control and status
general Boolean ST Dchg M
dirGeneral Enumerated (Byte) ST Dchg unknown | forward | backward | both M
phsA Boolean ST Dchg GC_2(1)
dirPhsA Enumerated (Byte) ST dchg unknown | forward | backward GC_2(1)
phsB Boolean ST dchg GC_2(2)
dirPhsB Enumerated (Byte) ST dchg unknown | forward | backward GC_2(2)
phsC Boolean ST dchg GC_2(3)
dirPhsC Enumerated (Byte) ST dchg unknown | forward | backward GC_2(3)
q Bvstring13 ST qchg M
t Utctime ST M
configuration, description and extension
d Vstring255 DC O
gePhsACD_1
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
control and status
general Boolean ST Dchg M
dirGeneral Enumerated (Byte) ST Dchg unknown | forward | backward | both M
phsA Boolean ST Dchg GC_2(1)
dirPhsA Enumerated (Byte) ST dchg unknown | forward | backward GC_2(1)
phsB Boolean ST dchg GC_2(2)
dirPhsB Enumerated (Byte) ST dchg unknown | forward | backward GC_2(2)
phsC Boolean ST dchg GC_2(3)
dirPhsC Enumerated (Byte) ST dchg unknown | forward | backward GC_2(3)
q Bvstring13 ST qchg M
t Utctime ST M
configuration, description and extension
d Vstring255 DC O
dataNs Vstring255 EX AC_DLN_M
geNeutACD
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
control and status
general Boolean ST Dchg M
dirGeneral Enumerated (Byte) ST Dchg unknown | forward | backward | both M
q Bvstring13 ST qchg M
t Utctime ST M
configuration, description and extension
d Vstring255 DC O
geNeutACD_1
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
