7-110 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
3.1.6 Binary counter reading (BCR)
control and status
general Boolean ST Dchg M
dirGeneral Enumerated (Byte) ST Dchg unknown | forward | backward | both M
q Bvstring13 ST qchg M
t Utctime ST M
configuration, description and extension
d Vstring255 DC O
dataNs Vstring255 EX AC_DLN_M
geGeneralACD
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
control and status
general Boolean ST Dchg M
dirGeneral Enumerated (Byte) ST Dchg unknown | forward | backward | both M
q Bvstring13 ST qchg M
t Utctime ST M
configuration, description and extension
d Vstring255 DC O
BCR class (Binary counter reading)
geBCR
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
control and status
actVal Int64 ST Dchg M
q Bvstring13 ST qchg M
t Utctime ST M
configuration, description and extension
units Unit CF O
pulsQty Float32 CF M
d Vstring255 DC O
geBCR_1
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
control and status
actVal Int64 ST dchg M
frVal Int64 ST dchg GC_2_1
frTm Utctime ST GC_2_1
q Bvstring13 ST qchg M
t Utctime ST M
configuration, description and extension
pulsQty Float32 CF M
frEna Boolean CF GC_2_1
strTm Utctime CF GC_2_1
frPd Int32 CF GC_2_1
frRs Boolean CF GC_2_1
d Vstring255 DC O
geBCR_2
