CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-111
3.2 Common data class specifications for measurand information
3.2.1 Measured Value (MV)
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
control and status
actVal Int64 ST dchg M
frVal Int64 ST dchg GC_2_1
frTm Utctime ST GC_2_1
q Bvstring13 ST qchg M
t Utctime ST M
configuration, description and extension
pulsQty Float32 CF M
frEna Boolean CF GC_2_1
strTm Utctime CF GC_2_1
frPd Int32 CF GC_2_1
frRs Boolean CF GC_2_1
d Vstring255 DC O
dataNs Vstring255 EX AC_DLN_M
MV class (Measured value)
geFloatMV
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
measured attributes
instMag
f
FloatAnalogueValue MX
------
O
FLOAT32 GC_1
mag
f
FloatAnalogueValue MX dchg M
FLOAT32 GC_1
range ENUMERATED(Byte) MX dchg O
q BVstring13 MX qchg M
t Utctime MX M
Configuration, description and extension
units
SIUnit
Multiplier
Unit CF O
ENUMERATED(Byte)
M
ENUMERATED(Byte)
O
db
INT32U
CF O
zeroDb INT32U CF O
