CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-117
3.3 Common data class specifications for controllable status information
3.3.1 Controlable single point (SPC).
seqT enumerated MX Pos-neg-zero | dir-quad-zero O
configuration, description and extension
d Vstring255 DC O
SPC class
geSPC
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
control and status
stVal Boolean ST FALSE | TRUE AC_ST
q Quality ST AC_ST
t TimeStamp ST AC_ST
control and status
Oper ctlVal Boolean CO AC_CO_M
origin Originator CO AC_CO_M
orCat
ENUMERATED M
orIdent OCTECT64 M
ctlNum INT8U CO M
T Btime6 CO M
Test Boolean CO M
Check ENUMERATED CO M
configuration, description and extension
ctlModel ENUMERATED CF ctlModel M
operTimeout INT32U CF AC_CO_O
d Vstring255 DC O
geSPC_1
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
control and status
stVal Boolean ST FALSE | TRUE AC_ST
Q Quality ST AC_ST
t TimeStamp ST AC_ST
configuration, description and extension
ctlModel ENUMERATED CF ctlModel_1 M
d Vstring255 DC O
