7-118 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
3.3.2 Controllable double point (DPC)
DPC class (Controllable double point)
geDPC
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
control and status
Oper ctlVal Boolean CO AC_CO_M
origin Originator CO,ST AC_CO_M
orCat
ENUMERATED M
orIdent OCTECT64 M
ctlNum INT8U CO,ST M
T Btime6 CO M
Test Boolean CO M
Check ENUMERATED CO M
stVal CODE ENUM ST dchg intermediate-state | off | on | bad-
state
M
q BVstring13 ST qchg AC_ST
t Utctime ST AC_ST
configuration, description and extension
ctlModel ENUMERATED CF M
operTimeout INT32U CF AC_CO_O
d Vstring255 DC O
geDPC_1
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
control and status
Oper ctlVal Boolean CO AC_CO_M
origin Originator CO,ST AC_CO_M
orCat
ENUMERATED M
orIdent OCTECT64 M
ctlNum INT8U CO,ST M
T Btime6 CO M
Test Boolean CO M
Check ENUMERATED CO M
Cancel
SBO
SBOw
stVal CODE ENUM ST dchg intermediate-state | off | on | bad-
state
M
q BVstring13 ST qchg AC_ST
t Utctime ST AC_ST
configuration, description and extension
ctlModel ENUMERATED CF M
sboTimeout INT32U CF AC_CO_O
sboClass ENUMERATED CF AC_CO_O
operTimeout INT32U CF AC_CO_O
d Vstring255 DC O
geDPC_2
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
