CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-119
3.3.3 Controllable enumerated status (ENC).
3.4 Common data class specifications for status settings
3.4.1 Single point setting (SPG)
control and status
stVal CODE ENUM ST dchg intermediate-state | off | on | bad-
state
M
q BVstring13 ST qchg AC_ST
t Utctime ST AC_ST
configuration, description and extension
ctlModel ENUMERATED CF M
d Vstring255 DC O
ENC class (Controllable integer status)
geModENC (type Mod)
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
status
stVal Enum ST dcgh M
q BVstring13 ST qchg M
t Utctime ST M
configuration, description and extension
ctlModel ENUMERATED CF M
d Vstring255 DC O
SPG class
geSPG
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
setting
setVal Boolean SP AC_NSG_M
configuration, description and extension
d Vstring255 DC O
dataNs Vstring255 EX O
geSPG_1
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
setting
setVal Boolean SG AC_SG_M
configuration, description and extension
d Vstring255 DC O
dataNs Vstring255 EX O
