7-126 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
2 Logical Nodes and Extensions
Notation:
• M: Data is mandatory in the IEC-61850-7-4.
• O: Data is optional in the IEC-61850-7-4
and is used in the device.
• E: Data is an extension to the IEC-61850-7-4.
2.1 System Logical Nodes. LN Group: L
2.1.1 LPHD (Physical device information)
2.1.2 LLN0 (Logical node zero)
2.1.3 LGOS (GOOSE subscription)
This LN Logical is used for monitoring GOOSE messages, diagnosing the subscription state of a GOOSE message and has
24 instances inside the device
XCBR (Circuit breaker)
XSWI (Circuit switch)
LPHD class
Attribute
Name
Attr.
Type
Explanation M/O Notes
LPHD Physical device information M
Data
Common Logical Node Information
PhyNam geDPL Physical device name plate M
PhyHealth geHealthINS Physical device health M
Proxy geSPS Indicates if this LN is a proxy M
LLN0 class
Attribute
Name
Attr.
Type
Explanation M/O notes
LLN0 Logical node zero
Data
Common Logical Node Information
Mod geModINC Mode M
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL_1 Name plate M
Loc geSPS Local control behaviour O
OpTmh geINS Operation time O
GoCB (ACSI class GOOSE control block)
GoCB GoCB
LLN0 class
Attribute
Name
Attr.
Type
Explanation M/O notes
LLN0 Logical node zero
Data
Common Logical Node Information
Mod geModENC Mode M
Beh geBehENS Behaviour M
Health geHealthENS Health M
NamPlt geLPL Name plate M
