CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-127
2.1.4 GoCB (GOOSE control block class definition)
2.2 Logical Nodes for protection functions. LN Group:P
2.2.1 PIOC (Instantaneous overcurrent)
2.2.1.1 gePhsPIOC_2
This logical node class is used for phase instantaneous overcurrent and has 6 instances inside the device.
2.2.1.2 geNdPIOC_2
This logical node class is used for neutral instantaneous overcurrent and has 3 instances inside the device.
St geSPS Status of the subscription M
LastStNum geINS Last state number received O
ConfRevNum geINS Expected conf. revision num. O
GoCBRef geORG Ref. to the subscribed GOOSE control block O
GoCB class
Attribute Name Attribute Type FC notes
GoEna BOOLEAN GO Enable (TRUE), disable (FALSE)
GoID VISIBLE STRINGS GO
DatSet Object Reference GO
ConfRev INT32U GO
NdsCom BOOLEAN GO
DstAddress PHYCOMADDR GO
PIOC class
Attribute
Name
Attr.
Type
Explanation M/O notes
PIOC Instantaneous overcurrent
Data
Common Logical Node Information
Mod geModINC Mode M
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name plate M
Status Information
Str gePhsACD Start O IOC PKP
Op gePhsACT Operate M IOC OP
Blk geSPS_1 Block O
Settings
PIOCEna geSPG_2 Function O
InMagTyp geING_0_2 Input O
StrVal geFloatASG_2 Pickup level O
OpDlTmms geING_8_2 Trip delay O
RsDlTmms geING_8_2 Reset delay O
EventEna geSPG_2 Snapshot events enabled O
PIOC class
Attribute
Name
Attr.
Type
Explanation M/O notes
PIOC Instantaneous overcurrent
Data
