7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
2.2.1.3 geGndPIOC_2
This logical node class is used for ground instantaneous overcurrent (3 instances) and sensitive ground instantaneous
overcurrent (3 instances). There are 6 instances this logical node inside the device.
2.2.1.4 IsoGndPIOC_2
This logical node class is used for Isolated sensitive ground instantaneous overcurrent. There are 3 instances this logical
node inside the device.
Common Logical Node Information
Mod geModINC Mode M
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name plate M
Status Information
Str geNeutACD Start O IOC PKP
Op geNeutACT Operate M IOC OP
Blk geSPS_1 Block O
Settings
PIOCEna geSPG_2 Function O
StrVal geFloatASG_2 Pickup level O
OpDlTmms geING_8_2 Trip delay O
RsDlTmms geING_8_2 Reset delay O
EventEna geSPG_2 Snapshot events enabled O
PIOC class
Attribute
Name
Attr.
Type
Explanation M/O notes
PIOC Instantaneous overcurrent
Data
Common Logical Node Information
Mod geModINC Mode M
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name plate M
Status Information
Str gePhsACD Start O IOC PKP
Op gePhsACT Operate M IOC OP
Blk geSPS_1 Block O
Settings
PIOCEna geSPG_2 Function O
InMagTyp geING_0_2 Input O
StrVal geFloatASG_2 Pickup level O
OpDlTmms geING_8_2 Trip delay O
RsDlTmms geING_8_2 Reset delay O
EventEna geSPG_2 Snapshot events enabled O
PIOC class
Attribute
Name
Attr.
Type
Explanation M/O notes
PIOC Instantaneous overcurrent
Data
Common Logical Node Information
Mod geModINC Mode M
Beh geBehINS Behaviour M
Health geHealthINS Health M
