CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-129
2.2.1.5 geBknCndPIOC_2
This logical node class is used for broken conductor instantaneous overcurrent. There are 3 instances this logical node
inside the device.
NamPlt geLPL Name plate M
Status Information
Str gePhsACD Start O IOC PKP
Op gePhsACT Operate M IOC OP
Blk geSPS_1 Block O
Settings
PIOCEna geSPG_2 Function O
VhStr geIntASG_2 Vh level O
VIStr geIntASG_2 VI level O
IhStr geFloatASG_1_2 Ih level O
IIStr geFloatASG_1_2 II level O
OpDlTmms geING_8_2 Trip delay O
RsDlTmms geING_8_2 Reset delay O
EventEna geSPG_2 Snapshot events enabled O
PIOC class
Attribute
Name
Attr.
Type
Explanation M/O notes
PIOC Instantaneous overcurrent
Data
Common Logical Node Information
Mod geModINC Mode M
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name plate M
Status Information
Str gePhsACD Start O IOC PKP
Op gePhsACT Operate M IOC OP
Blk geSPS Block O
Settings
PIOCEna geSPG_2 Function O
StrVal geFloatASG_2 Pickup level O
OpDlTmms geING_8_2 Trip delay O
BlkCurrent geFloatASG_1_2 Operation Threshold O
EventEna geSPG_2 Snapshot events enabled O
