7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
2.2.2 PTOC (Time overcurrent)
2.2.2.1 gePhsPTOC_2
This logical node class is used for phase time overcurrent and has 6 instances inside the device.
2.2.2.2 geNdPTOC_2
This logical node class is used for neutral time overcurrent and has 3 instances inside the device.
PTOC class
Attribute
Name
Attr.
Type
Explanation M/O notes
PTOC Time overcurrent
Data
Common Logical Node Information
Mod geModINC Mode M
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name plate M
Status Information
Str gePhsACD Start O TOC PKP
Op gePhsACT Operate M TOC OP
Blk geSPS_1 Block O TOC BLK
Settings
PTOCEna geSPG_2 Function O
InMagTyp geING_0_2 Input O
TmACrv geCURVE_3 Curve O
StrVal geFloatASG_2 Pickup level O
VolRst geSPG_2 Voltage Restraint O
TmMult geFloatASG_2 TD Multiplier O
RsMod geING_0_2 Reset O
EventEna geSPG_2 Snapshot events enabled O
PTOC class
Attribute
Name
Attr.
Type
Explanation M/O notes
PTOC Time overcurrent
Data
Common Logical Node Information
Mod geModINC Mode M
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name plate M
Status Information
Str geNeutACD Start O TOC PKP
Op geNeutACT Operate M TOC OP
Blk geSPS Block O TOC BLK
Settings
PTOCEna geSPG_2 Function O
TmACrv geCURVE_3 Curve O
StrVal geFloatASG_2 Pickup level O
TmMult geFloatASG_2 TD Multiplier O
RsMod geING_0_2 Reset O
EventEna geSPG_2 Snapshot events enabled O
