CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-131
2.2.2.3 geGndPTOC_2
This logical node class is used for ground time overcurrent (3 instances) and for sensitive ground time overcurrent (3
instances). There are 6 instances inside of this logical node inside the device
2.2.2.4 geNgSeqPTOC_2
This logical node class is used for negative sequence time overcurrent function and has 3 instances inside the device.
PTOC class
Attribute
Name
Attr.
Type
Explanation M/O notes
PTOC Time overcurrent
Data
Common Logical Node Information
Mod geModINC Mode M
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name plate M
Status Information
Str gePhsACD Start M TOC PKP
Op gePhsACT Operate M TOC OP
Blk geSPS Block O TOC BLK
Settings
PTOCEna geSPG_2 Function O
InMagTyp geING_0_2 Input O
StrVal geFloatASG_2 Pickup level O
TmACrv geCURVE_3 Curve O
TmMult geFloatASG_2 TD Multiplier O
RsMod geING_0_2 Reset O
EventEna geSPG_2 Snapshot events enabled O
PTOC class
Attribute
Name
Attr.
Type
Explanation M/O notes
PIOC Time overcurrent
Data
Common Logical Node Information
Mod geModINC Mode M
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name plate M
Status Information
Str gePhsACD Start O TOC PKP
Op gePhsACT Operate M TOC OP
Blk geSPS Block O TOC BLK
Settings
PTOCEna geSPG_2 Function O
StrVal geFloatASG_2 Pickup level O
TmACrv geCURVE_3 Curve O
TmMult geFloatASG_2 TD Multiplier O
RsMod geING_0_2 Reset O
EventEna geSPG_2 Snapshot events enabled O
