7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
2.2.3 PTOF (OverFrequency)
2.2.3.1 gePTOF
This logical node class is used for overfrequency and has 6 instances inside the device.
2.2.4 PTUF (UnderFrequency)
2.2.4.1 gePTUF
This logical node class is used for underfrequency and has 6 instances inside the device.
PTOF class
Attribute Name Attribute type Explanation M/O/C/E Notes
PTOF Overfrequency
Data
Common Logical Node Information
Mod geModINC Mode M
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name Plate M
Status information
Str geGeneralACD Start M TOF PKP
Op geGeneralACT Operate M TOF OP
Blk geSPS_1 Block O TOF BLK
Settings
PTOFEna geSPG_2 Function E
StrVal geFloatASG_2 Start value (frequency) O
BlkVal geIntASG_3 Voltage block value O
OpDlTmms geING_8_2 Operate delay time O
RsDlTmms geING_8_2 Reset delay time O
FreqSource geSPG_2 Frequency source E
EventEna geSPG_2 Snapshot events enabled E
PTOF class
Attribute Name Attribute type Explanation M/O/C/E Notes
PTUF Underfrequency
Data
Common Logical Node Information
Mod geModINC Mode M
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name Plate M
Status information
Str geGeneralACD Start M TU PKP
Op geGeneralACT Operate M TUF OP
Blk geSPS_1 Block O TUF BLK
Settings
PTUFEna geSPG_2 Function E
StrVal geFloatASG_2 Start value (frequency) O
BlkVal geIntASG_3 Voltage block value O
OpDlTmms geING_8_2 Operate delay time O
RsDlTmms geING_8_2 Reset delay time O
FreqSource geSPG_2 Frequency source E
EventEna geSPG_2 Snapshot events enabled E
