CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-133
2.2.5 PTUV
2.2.5.1 gePhsPTUV_2
This logical node class is used for phase undervoltage and has 3 instances inside the device.
2.2.5.2 geAuxPTUV_2
This logical node class is used for auxiliary undervoltage and has 3 instances inside the device.
PTOV class
Attribute
Name
Attr.
Type
Explanation M/O notes
PTUV
Undervoltage
Data
Common Logical Node Information
Mod geModINC Mode M
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name plate M
Status Information
Str geGeneralACD Start M TUV PKP
Op geGeneralACT Operate M TUV OP
Blk geSPS_1 Block O TUV BLK
StrPhGn gePhsACD_1 Pickup Phase-Ground O
OpPhGn gePhsACT_1 Operate Phase-Ground O
StrPhPh gePhsACD_1 Pickup Phase-Phase O
OpPhPh gePhsACT_1 Operate Phase-Phase O
Settings
PTUVEna geSPG_2 Function O
InMod geING_0_2 Mode O
TmVCrv geCURVE_4 Operating Curve Type O
StrVal geIntASG_3 Start value O
TmMult geFloatASG_2 Time dial multiplier O
DeaLinVal geIntASG_3 Minimum Voltage O
PhLogic geING_0_2 Logic O
BkrMon geSPG_2 Supervised by 52 O
EventEna geSPG_2 Snapshot events enabled O
PTUV class
Attribute
Name
Attr.
Type
Explanation M/O notes
PTUV
Undervoltage
Data
Common Logical Node Information
Mod geModINC Mode M
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name plate M
Status Information
Str geGeneralACD Start M TUV PKP
Op geGeneralACT Operate M TUV OP
Blk geSPS_1 Block O TUV BLK
Settings
PTUVEna geSPG_2 Function O
TmVCrv geCURVE_4 Operating Curve Type O
StrVal geIntASG_3 Start value O
TmMult geFloatASG_2 Time dial multiplier O
EventEna geSPG_2 Snapshot events enabled O
