CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-135
2.2.6.3 geNeutPTOV_2
This logical node class is used for neutral overvoltage and has 6 instances inside the device.
2.2.6.4 geNgSeqPTOV_2
This logical node class is used for negative sequence overvoltage and has 3 instances inside the device.
PTOV class
Attribute
Name
Attr.
Type
Explanation M/O notes
PTOV Overvoltage
Data
Common Logical Node Information
Mod geModINC Mode M
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name plate M
Status Information
Str geGeneralACD Start M TOV PKP
Op geGeneralACT Operate M TOV OP
Blk geSPS_1 Block O TOV BLK
Settings
PTOVEna geSPG_2 Function O
StrVal geIntASG_3 Start value O
OpDlTmms geING_8_2 Operate delay time O
RsDlTmms geING_8_2 Reset delay time O
EventEna geSPG_2 Snapshot events enabled O
PTOV class
Attribute
Name
Attr.
Type
Explanation M/O notes
PTOV Overvoltage
Data
Common Logical Node Information
Mod geModINC Mode M
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name plate M
Status Information
Str geGeneralACD Start M TOV PKP
Op geGeneralACT Operate M TOV OP
Blk geSPS Block O TOV BLK
Settings
PTOVEna geSPG_2 Function O
StrVal geIntASG_3 Start value O
OpDlTmms geING_8_2 Operate delay time O
RsDlTmms geING_8_2 Reset delay time O
EventEna geSPG_2 Snapshot events enabled O
