7-136 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
2.2.7 PDOP (Directional Overpower)
All logical node classes described in this section have been included from firmware version 7.50.
2.2.7.1 geFwdPDOP_2
This logical node class shall be used to model the forward overpower function and has 3 instances inside the device.
2.2.7.2 geDirPDOP_2
This logical node class shall be used to model the directional overpower function and has 3 instances inside the device.
PDOP class
Attribute
Name
Attr.
Type
Explanation M/O notes
PDOP Overpower
Data
Common Logical Node Information
Mod geModINC Mode M
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name plate M
Status Information
Str gePhsACD Start M Stage 1 PKP
Op gePhsACT Operate M Stage 1 OP
Blk geSPS_1 Block O
S2Str gePhsACD_2 Start O Stage 2 PKP
S2Op gePhsACT_1 Operate O Stage 2 OP
Settings
PDOPEna geSPG_2 Function O
BlkClsTms geING_0_2 Blk time after close O
StrVal geFloatASG_2 Stage 1 Tap O
OpDlTmms geING_8_2 Stage 1 Time O
S2StrVal geFloatASG_2 Stage 2 Tap O
S2OpDlTmms geING_8_2 Stage 2 Time O
EventEna geSPG_2 Snapshot events enabled O
PDOP class
Attribute
Name
Attr.
Type
Explanation M/O notes
PDOP Overpower
Data
Common Logical Node Information
Mod geModINC Mode M
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name plate M
Status Information
Str gePhsACD Start M
Op gePhsACT Operate M
Blk geSPS_1 Block O
S1Str gePhsACD_2 Start O Stage 1 PKP
S1Op gePhsACT_1 Operate O Stage 1 OP
S2Str gePhsACD_2 Start O Stage 2 PKP
S2Op gePhsACT_1 Operate O Stage 2 OP
Settings
PDOPEna geSPG_2 Function O
BlkClsTms geING_0_2 Blk time after close O
S1DirPwAng geFloatASG_1_2 Dir Power Angle 1 O
S1StrVal geFloatASG_1_2 Stage 1 Tap O
S1OpDlTmms geING_0_2 Stage 1 Time O
S2DirPwAng geFloatASG_1_2 Dir Power Angle 2 O
S2StrVal geFloatASG_1_2 Stage 2 Tap O
