CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-137
2.2.7.3 geWattPDOP_2
This logical node class shall be used to model the wattmeter ground overpower function and has 6 instances inside the
device.
2.2.8 PFRC (Frequency Rate of Change)
2.2.8.1 gePFRC_2
This logical node class shall be used to model the frequency rate of change function and has three instances inside the
device.
S2OpDlTmms geING_0_2 Stage 2 Time O
EventEna geSPG_2 Snapshot events enabled O
PDOP class
Attribute
Name
Attr.
Type
Explanation M/O notes
PDOP Overpower
Data
Common Logical Node Information
Mod geModINC Mode M
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name plate M
Status Information
Str gePhsACD Start M
Op gePhsACT Operate M
Blk geSPS_1 Block O
SupStr gePhsACD_2 Start O
Settings
PDOPEna geSPG_2 Function O
OVStrVal geFloatASG_1_2 Voltage Pickup Level O
InMagTyp geING_0_2 Current Selection O
OCStrVal geFloatASG_1_2 OC Pickup level O
OCStrDlTms geING_0_2 OC Pickup Delay O
PWStrVal geFloatASG_1_2 Power Pickup O
ChrAng geFloatASG_2 MTA O
PWStrDlTms geING_0_2 Power Pickup Delay O
Curve geING_0_2 Curve O
MltTmms geING_0_2 Multiplier O
EventEna geSPG_2 Snapshot events enabled O
PFRC class
Attribute
Name
Attr.
Type
Explanation M/O notes
PFRC Frequency Rate of Change
Data
Common Logical Node Information
Mod geModINC Mode M
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name plate M
Status Information
Str gePhsACD Start M
Op gePhsACT Operate M
Blk geSPS_1 Block O
Settings
PFRCEna geSPG_2 Function O
Trend geING_0_2 Freq Rate Trend O
StrVal geFloatASG_2 Freq Rate Pickup O
BlkVal geFloatASG_2 Freq Rate Min Volt O
