7-138 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
2.2.9 PDIS (Distance)
2.2.9.1 gePDIS_2
This logical node class shall be used to model the load encroachment function and has three instances inside the device.
2.2.10 PTTR (Thermal overload)
2.2.10.1 gePTTR_2
This logical node shall be used to model the thermal overload functions and has three instances inside the device.
BlkMinFreq geFloatASG_1_2 Freq Rate Min Freq O
BlkMaxFreq geFloatASG_1_2 Freq Rate Max Freq O
OpDlTmms geING_8_2 Freq Rate Delay O
EventEna geSPG_2 Snapshot events O
PDIS class
Attribute
Name
Attr.
Type
Explanation M/O notes
PDIS Distance
Data
Common Logical Node Information
Mod geModINC Mode M
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name plate M
Status Information
Str gePhsACD Start M
Op gePhsACT Operate M
Blk geSPS_1 Block O
Settings
PDISEna geSPG_2 Function O
MinVoltage geFloatASG_1_2 Freq Rate Trend O
RisLod geFloatASG_2 Freq Rate Pickup O
AngLod geFloatASG_2 Freq Rate Min Volt O
OpDlTmms geING_8_2 Operation Delay O
RsDlTmms geING_8_2 Reset Delay O
EventEna geSPG_2 Snapshot events O
PTTR class
Attribute Name Attribute type Explanation M/O/C/E Notes
PTTR Thermal overload
Data
Common Logical Node Information
Mod geModINC Mode M
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name Plate M
Status information
Str geGeneralACD Start M
Op gePhsACT Operate M
Blk geSPS_1 Block O
AlmThm geGeneralACT Thermal alarm O
AlmThmPhA geSPS_1 Thermal alarm phase A E
AlmThmPhB geSPS_1 Thermal alarm phase B E
AlmThmPhC geSPS_1 Thermal alarm phase C E
Settings
PTTREna geSPG_2 Function E
ConsTmHeat geFloatASG_1_2 Heat time constant E
