2.7.2 XSWI (Circuit switch)
2.7.2.1 geXSWI
In the F650 there are up to 16 configurable switchgears. Currently sixteen XSWI and sixteen CSWI are implemented and
mapped to all switchgears in F650. XSWI and CSWI Logical Nodes can be seen as paired objects in F650 as one pair of
XSWI and CSWI map to the same switchgear. XSWI1 and CSWI1 map to Switchgear1, XSWI2 and CSWI2 map to
Switchgear2, etc. The difference between XSWI and CSWI in F650 is that control commands cannot be sent directly via
XSWI LN. Control commands have to be sent via CSWI LN. "Pos" attribute is not controllable in XSWI it has ctlModel =
Status-only. In order to control the switch mapped to given XSWI the corresponding CSWI LN should be used.
XCBR class
Attribute
Name
Attr.
Type
Explanation M/O notes
XSWI Circuit switch
Data
Common Logical Node Information
Mod geModINC Mode M
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name plate M
Status information
Loc geSPS Local operation M Local / Remote
EEHealth geEEHealthENS Ext. equipment health O
OpCnt geINS Operation counter M Breaker openings
Controls
Pos geDPC_2 Switch position M Breaker open, close
BlkOpn geSPC_1 Block opening M Virtual output
BlkClr geSPC_1 Block closing M Virtual output
SwTyp geSwTypENS Switch type M
SwOpCap geSwOpCapENS Switch operating capability
