2.7 Logical Nodes for switchgear. LN Group: X
2.7.1 XCBR (Circuit Breaker)
2.7.1.1 geXCBR -> 1 circuit breaker
This logical node is used for modelling the circuit breaker of F650 relay
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name plate M
Measured values
SupWh geBCR O
SupVArh geBCR O
DmdWh geBCR O
DmdVArh geBCR O
CntPsWh geFloatMV_1 O
CntNgWh geFloatMV_1 O
CntPsVArh geFloatMV_1 O
CntNgVArh geFloatMV_1 O
XCBR class
Attribute
Name
Attr.
Type
Explanation M/O notes
XCBR Circuit breaker
Data
Common Logical Node Information
Mod geModINC Mode M
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name plate M
Status information
Loc geSPS Local operation M Local / Remote
OpCnt geINS Operation counter M Breaker openings
SumSwARs O
CBOpCap geCBOpCapENS Cicruit breaker operating
capa
bility
O
Controls
Pos geDPC_1 Switch position M Breaker open, close
BlkOpn geSPC_1 Block opening M Virtual output
BlkClr geSPC_1 Block closing M Virtual output
Settings
ThAlSwA geFloatASG_1 Maximum KI2t O
SumSwATmms geFloatASG_1 KI2t Integ. Time O
ExNumTr geIntASG_1 Maximum Openings O
ExNumTr1hr geIntASG_1 Max.Openings 1 hour O
