7-150 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
2.6 Logical Nodes for metering and measurement. LN Group: M
2.6.1 MMXU (Measurement)
2.6.1.1 geMMXU
2.6.2 MSQI (Sequence and imbalance)
2.6.2.1 geMSQI
2.6.3 MMTR (Metering)
2.6.3.1 geMMTR
MMXU class
Attribute
Name
Attr.
Type
Explanation M/O notes
MMXU Measurement
Data
Common Logical Node Information
Mod geModINC Mode M
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name plate M
Measured values
TotW geFloatMV Total active power (P) O
TotVAr geFloatMV Total reactive power (Q) O
TotVA geFloatMV Total apparent power (S) O
TotPF geFloatMV Average power factor (PF) O
Hz geFloatMV Line Frequency O
PPV geFloatDEL Phase to phase voltages (VL1L2,...) O
PhV geFloatPhsWYE Phase to ground voltages (VL1ER, ...) O
A geFloatWYE Phase currents (IL1, ...) O
AuxV geFloatCMV_1 Auxiliary Phase Voltage O
BusHz geFloatMV_1
MSQI class
Attribute
Name
Attr.
Type
Explanation M/O notes
MSQI Measurement
Data
Common Logical Node Information
Mod geModINC Mode M
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name plate M
Measured values
SeqA geFloatSEQ O
SeqV geFloatSEQ O
MMTR class
Attribute
Name
Attr.
Type
Explanation M/O notes
MMTR Measurement
Data
Common Logical Node Information
Mod geModINC Mode M
