CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-149
2.5.1.6 geDigitalCountersGGIO
This logical node is used for modelling the eight digital counters of F650 relay.
GGIO class
Attribute
Name
Attr.
Type
Explanation M/O notes
GGIO Generic process I/O
Data
Common Logical Node Information
Mod geModENC Mode M
Beh geBehENS Behaviour M
Health geHealthENS Health M
NamPlt geLPL Name plate M
Status information
Cnt1 geBCR_2 Digital counter 1 O
.. .. .. ..
Cnt8 geBCR_2 Digital counter 8 O
CntBlk1 geSPS_1 Digital counter 1 block O
.. .. ..
CntBlk8 geSPS_1 Digital counter 8 block O
CntHi1 geSPS_1 Digital counter 1 high O
.. .. ..
CntHi8 geSPS_1 Digital counter 8 high O
CntEq1 geSPS_1 Digital counter 1 equal O
.. .. ..
CntEq8 geSPS_1 Digital counter 8 equal O
CntLo1 geSPS_1 Digital counter 1 low O
.. .. ..
CntLo8 geSPS_1 Digital counter 8 low O
CntUp1 geSPS_1 Digital counter 1 up O
.. .. ..
CntUp8 geSPS_1 Digital counter 8 up O
CntDwn1 geSPS_1 Digital counter 1 down O
.. .. ..
CntDwn8 geSPS_1 Digital counter 8 down O
CntSetPre1 geSPS_1 Digital counter 1 set preset O
.. .. ..
CntSetPre8 geSPS_1 Digital counter 8 set preset O
CntRst1 geSPS_1 Digital counter 1 reset O
.. .. ..
CntRst8 geSPS_1 Digital counter 8 reset O
CntFrzRst1 geSPS_1 Digital counter 1 FreezeReset O
.. .. ..
CntFrzRst8 geSPS_1 Digital counter 8 FreezeReset O
CntFrzCnt1 geSPS_1 Digital counter 1 FreezeCount O
.. .. ..
CntFrzCnt8 geSPS_1 Digital counter 8 FreezeCount O
To Next Page
