7-148 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
2.5.1.4 geRemoteInputsGGIO
This logical node class is used to map data from incoming GOOSE messages.
2.5.1.5 geRemoteOutputsGGIO
This logical node class is used to map PLC digital states for outgoing GOOSE messages.
GGIO class
Attribute
Name
Attr.
Type
Explanation M/O notes
GGIO Generic process I/O
Data
Common Logical Node Information
Mod geModENC Mode M
Beh geBehENS Behaviour M
Health geHealthENS Health M
NamPlt geLPL Name plate M
Status information
Ind1 geSPS Remote digital input 1 O
Ind2 geSPS Remote digital input 2 O
.. .. .. ..
Ind64 geSPS Remote digital input 32 O
AnIn1 geFloatMV Remote float input 1 O
AnIn2 geFloatMV Remote float input 2 O
.. .. .. ..
AnIn8 geFloatMV Remote float input 8 O
AnIn9 geIntMV_1 Remote integer input 1 O
AnIn10 geIntMV_1 Remote integer input 2 O
.. .. .. ..
AnIn16 geIntMV_1 Remote integer input 8 O
Settings
OscTmms geING_0 Oscillation time remote inputs O
NumChgs geING_0 Number of transient changes O
GGIO class
Attribute
Name
Attr.
Type
Explanation M/O notes
GGIO Generic process I/O
Data
Common Logical Node Information
Mod geModENC Mode M
Beh geBehENS Behaviour M
Health geHealthENS Health M
NamPlt geLPL Name plate M
Status information
Ind1 geSPS Remote digital output 1 O
Ind2 geSPS Remote digital output 2 O
.. .. .. ..
Ind32 SgePS Remote digital output 32 O
