CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-147
2.5.1.2 geVirtualGGIO
This logical node class is used is used to map the latched and self reset virtual Inputs.
2.5.1.3 geEventsGGIO
This logical node class is used to map data from the list of any all internal digital states (PLC control events).
PlsOutms01 geING_0 Pulse time output 1 O
PlsOutms02 geING_0 Pulse time output 2 O
.. .. ..
PlsOutms16 geING_0 Pulse time output 16 O
Rng01 geING_0 Range analog input 1 O
Rng02 geING_0 Range analog input 2 O
.. .. .. ..
Rng08 geING_0 Range analog input 8 O
OscTmmsA geING_0 Oscillation time A O
OscTmmsB geING_0 Oscillation time B O
OscTmmsC geING_0 Oscillation time C O
OscTmmsD geING_0 Oscillation time D O
NumChgs geING_0 Number of transient changes O
EventEna geSPG Snapshot Events enabled O
GGIO class
Attribute
Name
Attribute
Type
Explanation M/O/E Notes
GGIO Ge ner i c pro c ess I / O
Data
Common Logical Node Information
Mod geModINC Mode M Status-only
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name plate M
Controls
DPCSO01 geSPC Virtual input 1 O
DPCSO01 geSPC Virtual input 2 O
.. .. .. ..
DPCSO64 geSPC Virtual input 32 O
GGIO class
Attribute
Name
Attribute
Type
Explanation M/O/E Notes
GGIO Ge ner i c pro c ess I / O
Data
Common Logical Node Information
Mod geModINC Mode M Status-only
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name plate M
Status information
Ind1 geSPS Control Event 1 O
Ind2 SPS Control Event 2 O Control Event 2
......... .......... ............... .......... ..............
Ind192 SPS Control Event 32 O Control Event 32
