7-146 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
2.5 Logical Nodes for generic references. LN Group: G
2.5.1 GGIO (Generic process I/O)
2.5.1.1 geBoardGGIO
This logical node class is used is used to map digital and analogue inputs of I/O boards F, G, H and J.
GGIO class
Attribute
Name
Attr.
Type
Explanation M/O notes
GGIO Generic process I/O
Data
Common Logical Node Information
Mod geModINC Mode M
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name plate M
Status information
BoardSt geSPS_1 Board status O
Ind1 geSPS Status contact input 1 O
Ind2 geSPS Status contact input 2 O
.. .. .. ..
Ind32 geSPS Status contact input 32 O
Ind33 geSPS Status contact output 1 O
.. .. ..
Ind48 geSPS Status contact output 16 O
Measured and metered values
AnIn1 geFloatMV Analog input 1 O
AnIn2 geFloatMV Analog input 2 O
.. .. ..
AnIn8 geFloatMV Analog input 8 O
Settings
VThrldA geIntASG_1 Voltage threshold A O
VThrldB geIntASG_1 Voltage threshold B O
VThrldC geIntASG_1 Voltage threshold C O
VThrldD geIntASG_1 Voltage threshold D O
DbceTmmsA geING_0 Debounce time A O
DbceTmmsB geING_0 Debounce time B O
DbceTmmsC geING_0 Debounce time C O
DbceTmmsD geING_0 Debounce time D O
InTyp01 geING_0 Type input 1 O
InTyp02 geING_0 Type input 2 O
.. .. .. ..
InTyp32 geING_0 Type input 32 O
DlInTmms01 geING_0 Delay time input 1 O
DlInTmms02 geING_0 Delay time input 2 O
.. .. .. ..
DlInTmms32 geING_0 Delay time input 32 O
OutLogic01 geING_0 Logic output 1
O
OutLogic02 geING_0 Logic output 2 O
.. .. .. ..
OutLogic16 geING_0 Logic output 16 O
OutTyp01 geING_0 Type output 1 O
OutTyp02 geING_0 Type output 2 O
.. .. ..
OutTyp16 geING_0 Type output 16 O
