CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-145
2.4 Logical Nodes for control. LN Group: C
2.4.1 CSWI (Switch controller)
2.4.1.1 geCSWI
In the F650 there are up to 16 configurable switchgears. Currently sixteen XSWI and sixteen CSWI are implemented and
mapped to first nine switchgears in F650. XSWI and CSWI Logical Nodes can be seen as paired objects in F650 as one pair
of XSWI and CSWI map to the same switchgear. XSWI1 and CSWI1 map to Switchgear1, XSWI2 and CSWI2 map to
Switchgear2, etc. The difference between XSWI and CSWI in F650 is that control commands cannot be sent directly via
XSWI LN. Control commands have to be sent via CSWI LN.
2.4.2 CILO (Interlocking)
2.4.2.1 geCILO -> 16 switchgear
This logical node class is used for interlocking the operations performed over the
switchgears and has 16 instances inside the device.
CSWI class
Attribute Name Attribute Type Explanation M/O/E Notes
CSWI Switch controller
Data
Common Logical Node Information
Mod geModINC Mode M Status-only
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name plate M
Controls
Loc geSPS Local operation O Local/Remote
Pos geDPC_1 Switch position M Switch open, close, undefined
CILO class
Attribute
Name
Attr.
Type
Explanation M/O notes
CILO Switch controller
Data
Common Logical Node Information
Mod geModINC Mode M
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name plate M
Status information
EnaOpn geSPS Enable Open M
EnaCls geSPS Enable Close
