7-144 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
2.3.6 RDRE (Disturbance recorder function)
This logical node class is used modelling the disturbance recording function and has 1 instance inside the device. RBDR
and RDRE logical nodes make available all attributes needed for the COMTRADE file.
2.3.7 RBDR (Disturbance recorder channel binary):
This logical node class is used for providing the circuit component and phase identification and has 1 instance inside the
device. RBDR and RDRE logical nodes make available all attributes needed for the COMTRADE file.
RDRE class
Attribute Name Attribute type Explanation M/O/C/E Notes
RDRE Disturbance recorder
Data
Common Logical Node Information
Mod geModINC Mode M Status-only
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name Plate M
Status information
RcdMade geSPS Recording made M
FltNum geINS Fault number M
CycRcd geINS_1 Cycles per record E
RcdNum geINS_1 Available records E
Settings
RDREEna geSPG Oscillography function enable E
TrgPos geINS_0 Trigger position E
SmpCyc geINS_10 Samples per cycle E
MaxNumRcd geINS_8 Maximum number of records O
RcdMod geINS_11 Recorder operation mode O
EventEna geSPG Snapshot events enabled E
RBDR class
Attribute Name Attribute type Explanation M/O/C/E Notes
RBDR Disturbance recorder channel binary
Data
Common Logical Node Information
Mod geModINC Mode M Status-only
Beh geBehINS Behaviour M
Health geHealthINS Health M
NamPlt geLPL Name Plate M
Status information
ChTrg geSPS Channel triggered M
FltNum geINS Fault Number M
DigCh01 geSPS_01 O
… … … …
DigCh16 geSPS_01 O
