7-164 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
3.2.4 Phase to phase related measured values of a three phase system ( DEL )
3.2.5 Sequence (SEQ)
3.3 Common data class specifications for controllable status information
3.3.1 Controllable single point (SPC).
d Vstring255 DC O
geFloatWYE
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
Data
phsA CMV_0 GC_1
phsB CMV_0 GC_1
phsC CMV_0 GC_1
neut CMV_0 GC_1
net CMV_0 GC_1
res CMV_0 GC_1
configuration, description and extension
d Vstring255 DC O
DEL class (Phase to phase related measured values of a three phase system)
geFloatDEL
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
Data
phsAB CMV_0 GC_1
phsBC CMV_0 GC_1
phsCA CMV_0 GC_1
configuration, description and extension
d Vstring255 DC O
SEQ class ( Sequence )
geFloatSEQ
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
Data
c1 CMV_0 GC_1
c2 CMV_0 GC_1
c3 CMV_0 GC_1
Measured attributes
seqT enumerated MX Pos-neg-zero | dir-quad-zero O
configuration, description and extension
d Vstring255 DC O
SPC class
geSPC
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
