3.3.2 Controllable double point (DPC)
DataAttribute
control and status
stVal Boolean ST FALSE | TRUE AC_ST
q Quality ST AC_ST
t TimeStamp ST AC_ST
control and status
Oper ctlVal Boolean CO AC_CO_M
origin Originator CO AC_CO_M
orCat
ENUMERATED M
orIdent OCTECT64 M
ctlNum INT8U CO M
T Btime6 CO M
Test Boolean CO M
Check ENUMERATED CO M
configuration, description and extension
ctlModel ENUMERATED CF ctlModel M
operTimeout INT32U CF AC_CO_O
d Vstring255 DC O
cdcNs Vstring255 EX
cdcName Vstring255 EX
geSPC_1
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
control and status
stVal Boolean ST FALSE | TRUE AC_ST
Q Quality ST AC_ST
t TimeStamp ST AC_ST
configuration, description and extension
ctlModel ENUMERATED CF ctlModel_1 M
d Vstring255 DC O
DPC class (Controllable double point)
geDPC
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
control and status
Oper ctlVal Boolean CO AC_CO_M
origin Originator CO,ST AC_CO_M
orCat
ENUMERATED M
orIdent OCTECT64 M
ctlNum INT8U CO,ST M
T Btime6 CO M
Test Boolean CO M
Check ENUMERATED CO M
stVal CODE ENUM ST dchg intermediate-state | off | on | bad-
state
M
q BVstring13 ST qchg AC_ST
t Utctime ST AC_ST
configuration, description and extension
ctlModel ENUMERATED CF M
