7-172 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
3.5.2 Setting curve (CURVE)
configuration, description and extension
Units Unit CF
minVal
f
FloatAnalogueValue CF O
FLOAT32 GC_1
maxVal
f
FloatAnalogueValue CF O
FLOAT32 GC_1
stepSize
f
FloatAnalogueValue CF O
FLOAT32 GC_1
d Vstring255 DC O
dataNs Vstring255 EX O
geFloatASG_2
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
setting
setMag
f
FloatAnalogueValue SG AC_SG_M
FLOAT32 GC_1
configuration, description and extension
Units Unit CF
minVal
f
FloatAnalogueValue CF O
FLOAT32 GC_1
maxVal
f
FloatAnalogueValue CF O
FLOAT32 GC_1
stepSize
f
FloatAnalogueValue CF O
FLOAT32 GC_1
d Vstring255 DC O
geCURVE_3
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
setting
setCharact ENUMERATED SG O
d Vstring255 DC O
geCURVE_4
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
setting
setCharact ENUMERATED SG O
d Vstring255 DC O
