CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-173
3.6 Common data class specifications for description information
3.6.1 Device name plate (DPL)
3.6.2 Logical node name plate (LPL)
DPL class (Device name plate)
geDPL
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
control and status
vendor Vstring255 DC M
hwRev Vstring255 DC O
swRev Vstring255 DC O
serNum Vstring255 DC O
model Vstring255 DC O
LPL class (Logical node name plate)
geLPL
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
control and status
vendor Vstring255 DC M
swRev Vstring255 DC M
d Vstring255 DC M
configRev Vstring255 DC AC_LN0_M
geLPL_1
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
control and status
vendor Vstring255 DC M
swRev Vstring255 DC M
d Vstring255 DC M
configRev Vstring255 DC AC_LN0_M
ldNs Vstring255 EX O
