CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-189
GSSE
6 PIXIT for Control model
Description Value / Clarification
What elements of a subscribed GSSE header are checked
t
o decide the message is valid and the allData values are
accepted? If yes, describe the conditions.
For example:
Destination MAC address = as multicast
SendingIED = valid reference, not NULL
timeAllowedtoLive > 0
numDatSetEntries = matches with number of datSet
m
embers & allData members
N source MAC address
Y destination MAC address
Y timeAllowedtoLive
Y SendingIED
N t
N stNum
N sqNum
Y numDatSetEntries
What is the behaviour when one subscribed GSSE
m
essage isn’t received or syntactically incorrect (missing
GSSE)
A single “missing” GSSE message is ignored.
What is the behaviour when one subscribed GSSE
m
essage exceeds the previous time Allowed to Live (TAL)
It signals this GSSE as “offline”.
What is the behaviour when a subscribed GSSE message
is out
-of-order
Sequence number is ignored.
What is the behaviour when a subscribed GSSE message
is dupl
icated
Sequence number is ignored.
Description Value / Clarification
What control modes are supported: Y status-only
Y direct-with-normal-security
Y sbo-with-normal-security
Y direct-with-enhanced-security
Y sbo-with-enhanced-security
Note: control models:
-sbo-with-normal-security
-direct-with-enhanced-security
-sbo-with-enhanced-security
are available only for Pos attribute in logical nodes XCBR
an
d CSWI
Is Time activated operate (operTm) supported N
What is the behaviour of the DUT when the test attribute
is set
in the SelectWithValue and/or Operate request
DUT ignores the test value and executes the command as
usual
What are the conditions for the time (T) attribute in the
SelectW
ithValue and/or Operate request
DUT ignores the test value and executes the command as
usual.
Is “operate-many” supported N
Is pulse configuration supported N
What check conditions are supported N synchrocheck
N interlock-check
