7-190 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
Description(cont.) Value / Clarification(cont.)
What service error types are supported Y instance-not-available
Y instance-in-use
Y access-violation
Y access-not-allowed-in-current-state
Y parameter-value-inappropriate
Y parameter-value-inconsistent
Y class-not-supported
Y instance-locked-by-other-client
Y control-must-be-selected
Y type-conflict
Y failed-due-to-communications-constraint
Y failed-due-to-server-constraint
What additional cause diagnosis are supported N Unknown
Y Not-supported
N Blocked-by-switching-hierarchy
N Select-failed
Y Invalid-position
Y Position-reached
N Parameter-change-in-execution
N Step-limit
N Blocked-by-Mode
N Blocked-by-process
N Blocked-by-interlocking
N Blocked-by-synchrocheck
Y Command-already-in-execution
N Blocked-by-health
N 1-of-n-control
N Abortion-by-cancel
Y Time-limit-over
N Abortion-by-trip
Y Object-not-selected
How to force a “test-not-ok” respond with
SelectW
ithValue request?
Not applicable.
How to force a “test-not-ok” respond with Operate
re
quest?
Not applicable.
Which origin categories are supported? What happens if
the orC
at is not supported?
orCat values are checked only for XCBR1$CO$Pos. The
permision to do the operation depends on the position of
LOCAL/REMOTE switch on the front panel of relay and also
on the orCat value received. The following table shows the
behaviour. “Yes” means operation is permitted “No” means
operation is not permitted.
OrCat
2,3,5,6
When invalid orCat is received or LOCAL/REMOTE switch is
in
LOCAL position then DUT responds with negative value
OBJECT-ACCESS-DENIED. Additionally in case of Direct
Control with Enhanced Scurity or SBO with Enhanced
Scurity when invalid orCat is received the DUT sends
InformationReport with AddCause = not-supported.
Does the IED accept an select/operate with the same
ctlV
al as the current status value?
Select: Y
Operate : N
Does the IED accept a select/operate on the same control
objec
t from 2 different clients at the same time?
Select: N
Operate : N for SBO, SBO Enhanced
Operate: Y for Direct-Control and Direct-Control Enhanced.
However in case of Direct-Control with Enhanced Security
a
s long as the control object has not returned to state
Ready the Operate request from the second client is
rejected.
