CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-193
2 PIXIT for Server model
Description Value / Clarification
Which analogue value (MX) quality bits are supported (can be set by
server)
Validity:
Y Good,
Y Invalid,
N Reserved,
Y Questionable
N Overflow
Y OutofRange
Y BadReference
N Oscillatory
Y Failure
N OldData
N Inconsistent
N Inaccurate
Source:
N Process
N Substituted
N Test
N OperatorBlocked
Which status value (ST) quality bits are supported (can be set by
server)
Validity:
Y Good,
Y Invalid,
N Reserved,
Y Questionable
N BadReference
Y Oscillatory
Y Failure
N OldData
N Inconsistent
N Inaccurate
Source:
Y Process
Y Substituted
Y Test
N OperatorBlocked
What is the maximum number of data object references in one
GetDataValues request
Deprecated
What is the maximum number of data object references in one
SetDataValues request
Deprecated
Which Mode values are supported
1
1. IEC 61850-6:2009 clause 9.5.6 states that if only a subrange of the enumeration value set is supported,
this shall be indicated within an ICD file by an enumeration type, where the unsupported values are missing
On Y
[On-]Blocked N
Test N
Test/Blocked N
Off N
