7-194 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
3 PIXIT for Dataset model
4 PIXIT for Substitution model
5 PIXIT for Setting group control model
6 PIXIT for Reporting model
Description Value / Clarification
What is the maximum number of data elements in one data set
(compare ICD setting)
576
How many persistent data sets can be created by one or more
clients
(this number includes predefined datasets)
NOT SUPPORTED
How many non-persistent data sets can be created by one or more
clients
NOT SUPPORTED
Description Value / Clarification
Are substituted values stored in volatile memory NOT SUPPORTED
Description Value / Clarification
What is the number of supported setting groups for each logical
device
3 groups for “PRO” logical device 3
What is the effect of when and how the non-volatile storage is
updated
(compare IEC 61850-8-1 $16.2.4)
The server saves to non-volatile storage 25
seconds after confirmation.
Can multiple clients edit the same setting group No
What happens if the association is lost while editing a setting group Lost Permission and EditSG = 0
Is EditSG value 0 allowed Yes
When ResvTms is not present how long is an edit setting group
locked
While EditSG > 0
Description Value / Clarification
The supported trigger conditions are
(compare PICS)
integrity Y
data change Y
quality change Y
data update N
general interrogation Y
The supported optional fields are sequence-number Y
report-time-stamp Y
reason-for-inclusion Y
data-set-name Y
data-reference Y
buffer-overflow Y
entryID Y
conf-rev Y
segmentation Y
Can the server send segmented reports Y
