CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-195
7 PIXIT for Logging model
Mechanism on second internal data change notification of the
same analogue data value within buffer period (Compare IEC
61850-7-2 $14.2.2.9)
Send report immediately
Multi client URCB approach
(compare IEC 61850-7-2:2003 $14.2.1)
Each URCB is visible to all clients
What is the format of EntryID Deprecated
What is the buffer size for each BRCB or how many reports can be
buffered
Buffer size = 50000 Bytes
Pre-configured RCB attributes that are dynamic, compare SCL
report settings
Deprecated
May the reported data set contain:
- structured data objects
- data attributes
Y
Y (timestamp attributes are not supported)
What is the scan cycle for binary events
Is this fixed, configurable
Event Driven
Fixed
Does the device support to pre-assign a RCB to a specific client in
the SCL
N
After restart of the server is the value of ConfRev restored from the
original configuration or retained prior to restart
Restored from original configuration
<additional items>
Description Value / Clarification
What is the default value of LogEna
(Compare IEC 61850-8-1 $17.3.3.2.1, the default value should be
FALSE)
NOT SUPPORTED
What is the format of EntryID Deprecated
Are there are multiple Log Control Blocks that specify the
Journaling of the same MMS NamedVariable and TrgOps and the
Event Condition
(Compare IEC 61850-8-1 $17.3.3.3.2)
NOT SUPPORTED
Pre-configured LCB attributes that cannot be changed online NOT SUPPORTED
