7-202 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
2 PIXIT for Server model
ID Ed Description Value / Clarification
Sr1 1, 2 Which analogue value (MX) quality bits are supported (can be set by
server)
Validity:
Y Good,
Y Invalid,
N Reserved,
Y Questionable
N Overflow
Y OutofRange
Y BadReference
N Oscillatory
Y Failure
N OldData
N Inconsistent
N Inaccurate
Source:
N Process
N Substituted
N Test
N OperatorBlocked
Sr2 1, 2 Which status value (ST) quality bits are supported (can be set by
server)
Validity:
Y Good,
Y Invalid,
N Reserved,
Y Questionable
N BadReference
Y Oscillatory
Y Failure
N OldData
N Inconsistent
N Inaccurate
Source:
Y Process
Y Substituted
Y Test
N OperatorBlocked
Sr3 - What is the maximum number of data object references in one
GetDataValues request
Deprecated
Sr4 - What is the maximum number of data object references in one
SetDataValues request
Deprecated
Sr5 1
Which Mode values are supported
1
1. IEC 61850-6:2009 clause 9.5.6 states that if only a subrange of the enumeration value set is supported, this shall be
indicated within an ICD file by an enumeration type, where the unsupported values are missing
On Y
[On-]Blocked N
Test N
Test/Blocked N
Off N
