CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-203
3 PIXIT for Dataset model
4 PIXIT for Substitution model
5 PIXIT for Setting group control model
6 PIXIT for Reporting model
ID Ed Description Value / Clarification
Ds1 1 What is the maximum number of data elements in one data set
(compare ICD setting)
576
Ds2 1 How many persistent data sets can be created by one or more
clients
(this number includes predefined datasets)
NOT SUPPORTED
Ds3 1 How many non-persistent data sets can be created by one or more
clients
NOT SUPPORTED
ID Ed Description Value / Clarification
Sb1 1 Are substituted values stored in volatile memory NOT SUPPORTED
ID Ed Description Value / Clarification
Sg1 What is the number of supported setting groups for each logical
device
6 groups for “PRO” logical device 3
Sg2 What is the effect of when and how the non-volatile storage is
updated
(compare IEC 61850-8-1 $16.2.4)
The server saves to non-volatile storage 25
seconds after confirmation.
Sg3 Can multiple clients edit the same setting group No
Sg4 What happens if the association is lost while editing a setting group Lost Permission and EditSG = 0
Sg5 Is EditSG value 0 allowed Yes
Sg6 When ResvTms is not present how long is an edit setting group
locked
While EditSG > 0
ID Ed Description Value / Clarification
Rp1 1 The supported trigger conditions are
(compare PICS)
integrity Y
data change Y
quality change Y
data update N
general interrogation Y
Rp2 1 The supported optional fields are sequence-number Y
report-time-stamp Y
reason-for-inclusion Y
data-set-name Y
data-reference Y
buffer-overflow Y
entryID Y
conf-rev Y
segmentation Y
Rp3 1, 2 Can the server send segmented reports Y
