7-204 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
7 PIXIT for Logging model
8 PIXIT for GOOSE publish model
Rp4 1, 2 Mechanism on second internal data change notification of the
same analogue data value within buffer period (Compare IEC
61850-7-2 $14.2.2.9)
Send report immediately
Rp5 1 Multi client URCB approach
(compare IEC 61850-7-2:2003 $14.2.1)
Each URCB is visible to all clients
Rp6 - What is the format of EntryID Deprecated
Rp7 1, 2 What is the buffer size for each BRCB or how many reports can be
buffered
Buffer size = 50000 Bytes
Rp8 - Pre-configured RCB attributes that are dynamic, compare SCL
report settings
Deprecated
Rp9 1 May the reported data set contain:
- structured data objects
- data attributes
Y
Y (timestamp attributes are not supported)
Rp10 1, 2 What is the scan cycle for binary events
Is this fixed, configurable
Event Driven
Fixed
Rp11 1 Does the device support to pre-assign a RCB to a specific client in
the SCL
N
Rp12 2 After restart of the server is the value of ConfRev restored from the
original configuration or retained prior to restart
Restored from original configuration
<additional items>
ID Ed Description Value / Clarification
Lg1 1, 2 What is the default value of LogEna
(Compare IEC 61850-8-1 $17.3.3.2.1, the default value should be
FALSE)
NOT SUPPORTED
Lg2 - What is the format of EntryID Deprecated
Lg3 1, 2 Are there are multiple Log Control Blocks that specify the
Journaling of the same MMS NamedVariable and TrgOps and the
Event Condition
(Compare IEC 61850-8-1 $17.3.3.3.2)
NOT SUPPORTED
Lg4 1 Pre-configured LCB attributes that cannot be changed online NOT SUPPORTED
ID Ed Description Value / Clarification
Gp1 1, 2 Can the test (Ed1) / simulation (Ed2) flag in the published GOOSE be
set
N
Gp2 1 What is the behaviour when the GOOSE publish configuration is
incorrect
DUT keeps GoEna=F.
Configuration tool does not allow wrong
configuration to be uploaded into device. E.g.:
empty dataset.
Gp3 1, 2 Published FCD supported common data classes are SPS, INS, ENS, ACT, ACD, MV, CMV, SAV, WYE,
DEL, SEQ, INC, ENC, SPC, DPC, INC, ENC. (Only
the elements with FC=ST or MX are published).
Gp4 1, 2 What is the slow retransmission time
Is it fixed or configurable
Configured by SCL or GoCB MaxTime
Gp5 1, 2 What is the fastest retransmission time
Is it fixed or configurable
Fixed. MinTime = 5 ms
Gp6 - Can the GOOSE publish be turned on / off by using
SetGoCBValues(GoEna)
Y
