A-6 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
A.1 OPERANDS - F650 - MODEL FX - GX APPENDIX A: LOGIC OPERANDS
Switchgear states (16 elements)
SWITCH 1 OPEN switchgear 1 open
SWITCH 1 CLOSED switchgear 1 closed
SWITCH 1 00_ERROR Error 00 switchgear 1 (contact A = 0, contact B = 0)
SWITCH 1 11_ERROR Error 11 switchgear 1 (contact A = 1, contact B = 1)
SWITCH 2 OPEN Switchgear 2 open
SWITCH 2 CLOSED Switchgear 2 closed
SWITCH 2 00_ERROR Error 00 switchgear 2 (contact A = 0, contact B = 0)
SWITCH 2 11_ERROR Error 11 switchgear 2 (contact A = 1, contact B = 1)
... ...
SWITCH 16 OPEN Switchgear 16 open
SWITCH 16 CLOSED Switchgear 16 closed
SWITCH 16 00_ERROR Error 00 switchgear 16 (contact A = 0, contact B = 0)
SWITCH 16 11_ERROR Error 11 switchgear 16 (contact A = 1, contact B = 1)
Switchgear Open-Close Initializing States
SWITCH 1 OPEN INIT Switchgear 1 opening initiation
SWITCH 1 CLOSE INIT Switchgear 1 closing initiation
SWITCH 2 OPEN INIT Switchgear 2 opening initiation
SWITCH 2 CLOSE INIT Switchgear 2 closing initiation
... ...
SWITCH 16 OPEN INIT Switchgear 16 opening initiation
SWITCH 16 CLOSE INIT Switchgear 16 closing initiation
Switchgear Fail States
SWGR 1 FAIL TO OPEN Failure to open Switchgear 1
SWGR 2 FAIL TO OPEN Failure to open Switchgear 2
... ...
SWGR 16 FAIL TO OPEN Failure to open Switchgear 16
SWGR 1 FAIL TO CLOSE Failure to close Switchgear 1
SWGR 2 FAIL TO CLOSE Failure to close Switchgear 2
... ...
SWGR 16 FAIL TO CLOSE
Failure to close Switchgear 16
OPERANDS - F650 - MODEL FX - GX
Internal System Status
