APPENDIX A: LOGIC OPERANDS A.1 OPERANDS - F650 - MODEL FX - GX
GEK-106310-AF F650 DIGITAL BAY CONTROLLER A-7
LEDS HMI (16 Elements)
READY LED
Ready LED: (0-Red) Relay out of service, protection OUT
OF ORDER
(1-Green) Relay in service; protection READY
LED 1
Programmable LED 1 status: Red colour. Latched by
har
dware. Reset by hardware (ESC) and programmable
(LED RESET INPUT)
LED 2
Programmable LED 2 status: Red colour. Latched by
har
dware. Reset by hardware (ESC) and programmable
(LED RESET INPUT)
LED 3
Programmable LED 3 status: Red colour. Latched by
har
dware. Reset by hardware (ESC) and programmable
(LED RESET INPUT)
LED 4
Programmable LED 4 status: Red colour. Latched by
har
dware. Reset by hardware (ESC) and programmable
(LED RESET INPUT)
LED 5
Programmable LED 5 status: Red colour. Latched by
har
dware. Reset by hardware (ESC) and programmable
(LED RESET INPUT)
LED 6
Programmable LED 6 status: Orange colour. Not
latched
. Latching possibility via PLC. Reset by hardware
(ESC) and programmable (LED RESET INPUT)
LED 7
Programmable LED 7 status: Orange colour. Not
latched
. Latching possibility via PLC. Reset by hardware
(ESC) and programmable (LED RESET INPUT)
LED 8
Programmable LED 8 status: Orange colour. Not
latched
. Latching possibility via PLC. Reset by hardware
(ESC) and programmable (LED RESET INPUT)
LED 9
Programmable LED 9 status: Orange colour. Not
latched
. Latching possibility via PLC. Reset by hardware
(ESC) and programmable (LED RESET INPUT)
LED 10
Programmable LED 10 status: Orange colour. Not
latched
. Latching possibility via PLC. Reset by hardware
(ESC) and programmable (LED RESET INPUT)
LED 11
Programmable LED 11 status: Green colour. Not
latched
. Latching possibility via PLC. Reset by hardware
(ESC) and programmable (LED RESET INPUT)
LED 12
Programmable LED 12 status: Green colour. Not
latched
. Latching possibility via PLC. Reset by hardware
(ESC) and programmable (LED RESET INPUT)
LED 13
Programmable LED 13 status: Green colour. Not
latched
. Latching possibility via PLC. Reset by hardware
(ESC) and programmable (LED RESET INPUT)
LED 14
Programmable LED 14 status: Green colour. Not
latched
. Latching possibility via PLC. Reset by hardware
(ESC) and programmable (LED RESET INPUT)
LED 15
Programmable LED 15 status: Green colour. Not
latched
. Latching possibility via PLC. Reset by hardware
(ESC) and programmable (LED RESET INPUT)
LEDs reset input (programmable) LED RESET INPUT Programmable input for remote LED reset
I Key I key operation (Programmable signal via PLC)
O Key O key operation (Programmable signal via PLC)
Programmable Keypad Status (HMI)
*/F3 Key */F3 key operation (Programmable signal via PLC)
OPERANDS - F650 - MODEL FX - GX
Internal System Status
To Next Page
