A-8 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
A.1 OPERANDS - F650 - MODEL FX - GX APPENDIX A: LOGIC OPERANDS
F1 Key F1 key operation (Programmable signal via PLC)
F2 Key F2 key operation (Programmable signal via PLC)
LOCAL/REMOTE Operation status LEDs
LOCAL/REMOTE
OPERA
TION MODE
Local/remote status for operations 1 = Local, 0 =
Rem
ote. Selectable through the front pushbutton
(Hardware) and also through communications
(software).
OPERATIONS BLOCKED
Operations OFF status (1) Command execution block
(oper
ations blocked both in local and remote
mode)
.Selectable through the front pushbutton
(Hardware) and also through communications
(software).
LOCAL/REMOTE/OFF Selection
CHANGE LOCAL-REMOTE Changing local-remote status by communications
CHANGE OP BLOCKED Operations Block-Unblock signal
HMI Backlight
HMI BACKLIGHT ON
"Switching on backlignt" signal (the display is switched
on by co
mmunications
HMI BACKLIGHT OFF
"Switching off backlignt" signal (the display is switched
o
ff by communications
Internal System Status (cont.)
Oscillography States
OSC DIG CHANNEL 1 Oscillography Digital channel 1 : (1) Active ; (0) Not Active
OSC DIG CHANNEL 2 Oscillography Digital channel 2 : (1) Active ; (0) Not Active
OSC DIG CHANNEL 3 Oscillography Digital channel 3 : (1) Active ; (0) Not Active
OSC DIG CHANNEL 4 Oscillography Digital channel 4 : (1) Active ; (0) Not Active
OSC DIG CHANNEL 5 Oscillography Digital channel 5 : (1) Active ; (0) Not Active
OSC DIG CHANNEL 6 Oscillography Digital channel 6 : (1) Active ; (0) Not Active
OSC DIG CHANNEL 7 Oscillography Digital channel 7 : (1) Active ; (0) Not Active
OSC DIG CHANNEL 8 Oscillography Digital channel 8 : (1) Active ; (0) Not Active
OSC DIG CHANNEL 9 Oscillography Digital channel 9 : (1) Active ; (0) Not Active
OSC DIG CHANNEL 10
Oscillography Digital channel 10: (1) Active ; (0) Not
Activ
e
OSC DIG CHANNEL 11
Oscillography Digital channel 11 : (1) Active ; (0) Not
Activ
e
OSC DIG CHANNEL 12
Oscillography Digital channel 12 : (1) Active ; (0) Not
Activ
e
OSC DIG CHANNEL 13
Oscillography Digital channel 13 : (1) Active ; (0) Not
Activ
e
OSC DIG CHANNEL 14
Oscillography Digital channel 14 : (1) Active ; (0) Not
Activ
e
OSC DIG CHANNEL 15
Oscillography Digital channel 15 : (1) Active ; (0) Not
Activ
e
OSC DIG CHANNEL 16
Oscillography Digital channel 16 : (1) Active ; (0) Not
Activ
e
OSCILLO TRIGGER Oscillo trigger activation (1) Active ; (0) Not active
Fault Report (Fault locator)
FAULT REPORT TRIGG Fault report trigger (1) Active ; (0) Not active
CLEAR FAULT REPORTS
Fault report removal from HMI and ModBus (volatile
me
mory)
Energy Counters
FREEZE ENERGY CNT Energy counter freeze
UNFREEZE ENERGY CNT Energy counter unfreeze
RESET ENERGY CNT
Energy counter reset
OPERANDS - F650 - MODEL FX - GX
Internal System Status
