A-10 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
A.1 OPERANDS - F650 - MODEL FX - GX APPENDIX A: LOGIC OPERANDS
Phase IOC High
PH IOC1 HIGH A BLK
Phase instantaneous overcurrent element block Group 1
pha
se A
PH IOC1 HIGH B BLK
Phase instantaneous overcurrent element block Group 1
pha
se B
PH IOC1 HIGH C BLK
Phase instantaneous overcurrent element block Group 1
pha
se C
PH IOC1 HIGH A PKP
Phase instantaneous overcurrent element pickup high
lev
el Group 1 phase A
PH IOC1 HIGH A OP
Phase instantaneous overcurrent element operation
(trip) high lev
el Group 1 phase A
PH IOC1 HIGH B PKP
Phase instantaneous overcurrent element pickup high
lev
el Group 1 phase B
PH IOC1 HIGH B OP
Phase instantaneous overcurrent element operation
(trip) high lev
el Group 1 phase B
PH IOC1 HIGH C PKP
Phase instantaneous overcurrent element pickup high
lev
el Group 1 phase C
PH IOC1 HIGH C OP
Phase instantaneous overcurrent element operation
(trip) high lev
el Group 1 phase C
PH IOC1 HIGH PKP
Phase instantaneous overcurrent element pickup high
lev
el Group 1 any phase
PH IOC1 HIGH OP
Phase instantaneous overcurrent element operation
(trip) high lev
el Group 1 any phase
PH IOC2 HIGH A BLK
Phase instantaneous overcurrent element block Group 2
pha
se A
PH IOC2 HIGH B BLK
Phase instantaneous overcurrent element block Group 2
pha
se B
PH IOC2 HIGH C BLK
Phase instantaneous overcurrent element block Group 2
pha
se C
PH IOC2 HIGH A PKP
Phase instantaneous overcurrent element pickup high
lev
el Group 2 phase A
PH IOC2 HIGH A OP
Phase instantaneous overcurrent element operation
(trip) high lev
el Group 2 phase A
PH IOC2 HIGH B PKP
Phase instantaneous overcurrent element pickup high
lev
el Group 2 phase B
PH IOC2 HIGH B OP
Phase instantaneous overcurrent element operation
(trip) high lev
el Group 2 phase B
PH IOC2 HIGH C PKP
Phase instantaneous overcurrent element pickup high
lev
el Group 2 phase C
PH IOC2 HIGH C OP
Phase instantaneous overcurrent element operation
(trip) high lev
el Group 2 phase C
PH IOC2 HIGH PKP
Phase instantaneous overcurrent element pickup high
lev
el Group 2 any phase
PH IOC2 HIGH OP
Phase instantaneous overcurrent element operation
(trip) high lev
el Group 2 any phase
PH IOC3 HIGH A BLK
Phase instantaneous overcurrent element block Group 3
pha
se A
PH IOC3 HIGH B BLK
Phase instantaneous overcurrent element block Group 3
phase B
OPERANDS - F650 - MODEL FX - GX
OPERANDS - F650 - MODEL FX - GX
Internal System Status
