Internal System Status (cont.)
Phase IOC High
PH IOC3 HIGH C BLK
Phase instantaneous overcurrent element block Group 3
pha
se C
PH IOC3 HIGH A PKP
Phase instantaneous overcurrent element pickup high
lev
el Group 3 phase A
PH IOC3 HIGH A OP
Phase instantaneous overcurrent element operation
(trip) high lev
el Group 3 phase A
PH IOC3 HIGH B PKP
Phase instantaneous overcurrent element pickup high
lev
el Group 3 phase B
PH IOC3 HIGH B OP
Phase instantaneous overcurrent element operation
(trip) high lev
el Group 3 phase B
PH IOC3 HIGH C PKP
Phase instantaneous overcurrent element pickup high
lev
el Group 3 phase C
PH IOC3 HIGH C OP
Phase instantaneous overcurrent element operation
(trip) high lev
el Group 3 phase C
PH IOC3 HIGH PKP
Phase instantaneous overcurrent element pickup high
lev
el Group 3 any phase
PH IOC3 HIGH OP
Phase instantaneous overcurrent element operation
(trip) high level Group 3 any phase
