A-12 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
A.1 OPERANDS - F650 - MODEL FX - GX APPENDIX A: LOGIC OPERANDS
Phase IOC Low
PH IOC1 LOW A BLK
Phase instantaneous overcurrent element block Low
lev
el Group 1 phase A
PH IOC1 LOW B BLK
Phase instantaneous overcurrent element block Low
lev
el Group 1 phase B
PH IOC1 LOW C BLK
Phase instantaneous overcurrent element block Low
lev
el Group 1 phase C
PH IOC1 LOW A PKP
Phase instantaneous overcurrent element pickup low
lev
el Group 1 phase A
PH IOC1 LOW A OP
Phase instantaneous overcurrent element operation
(trip) low lev
el Group 1 phase A
PH IOC1 LOW B PKP
Phase instantaneous overcurrent element pickup low
lev
el Group 1 phase B
PH IOC1 LOW B OP
Phase instantaneous overcurrent element operation
(trip) low lev
el Group 1 phase B
PH IOC1 LOW C PKP
Phase instantaneous overcurrent element pickup low
lev
el Group 1 phase C
PH IOC1 LOW C OP
Phase instantaneous overcurrent element operation
(trip) low lev
el Group 1 phase C
PH IOC1 LOW PKP
Phase instantaneous overcurrent element pickup low
lev
el Group 1 any phase
PH IOC1 LOW OP
Phase instantaneous overcurrent element operation
(trip) low lev
el Group 1 any phase
PH IOC2 LOW A BLK
Phase instantaneous overcurrent element block Low
lev
el Group 2 phase A
PH IOC2 LOW B BLK
Phase instantaneous overcurrent element block Low
lev
el Group 2 phase B
PH IOC2 LOW C BLK
Phase instantaneous overcurrent element block Low
lev
el Group 2 phase C
PH IOC2 LOW A PKP
Phase instantaneous overcurrent element pickup low
lev
el Group 2 phase A
PH IOC2 LOW A OP
Phase instantaneous overcurrent element operation
(trip) low lev
el Group 2 phase A
PH IOC2 LOW B PKP
Phase instantaneous overcurrent element pickup low
lev
el Group 2 phase B
PH IOC2 LOW B OP
Phase instantaneous overcurrent element operation
(trip) low lev
el Group 2 phase B
PH IOC2 LOW C PKP
Phase instantaneous overcurrent element pickup low
lev
el Group 2 phase C
PH IOC2 LOW C OP
Phase instantaneous overcurrent element operation
(trip) low lev
el Group 2 phase C
PH IOC2 LOW PKP
Phase instantaneous overcurrent element pickup low
lev
el Group 2 any phase
PH IOC2 LOW OP
Phase instantaneous overcurrent element operation
(trip) low lev
el Group 2 any phase
PH IOC3 LOW A BLK
Phase instantaneous overcurrent element block Low
level Group 3 phase A
OPERANDS - F650 - MODEL FX - GX
Internal System Status
