A-20 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
A.1 OPERANDS - F650 - MODEL FX - GX APPENDIX A: LOGIC OPERANDS
Phase Directional
PHASE DIR1 BLK INP Phase directional block Group 1
PHASE DIR1 BLOCK A Phase directional element block Group 1 Phase A
PHASE DIR1 A OP Phase directional element operation Group 1 Phase A
PHASE DIR1 BLOCK B Phase directional element block Group 1 Phase B
PHASE DIR1 B OP Phase directional element operation Group 1 Phase B
PHASE DIR1 BLOCK C Phase directional element block Group 1 Phase C
PHASE DIR1 C OP Phase directional element operation Group 1 Phase C
PHASE DIR2 BLK INP Phase directional block Group 2
PHASE DIR2 BLOCK A Phase directional element block Group 2 Phase A
PHASE DIR2 A OP Phase directional element operation Group 2 Phase A
PHASE DIR2 BLOCK B Phase directional element block Group 2 Phase B
PHASE DIR2 B OP Phase directional element operation Group 2 Phase B
PHASE DIR2 BLOCK C Phase directional element block Group 2 Phase C
PHASE DIR2 C OP Phase directional element operation Group 2 Phase C
PHASE DIR3 BLK INP Phase directional block Group 3
PHASE DIR3 BLOCK A Phase directional element block Group 3 Phase A
PHASE DIR3 A OP Phase directional element operation Group 3 Phase A
PHASE DIR3 BLOCK B Phase directional element block Group 3 Phase B
PHASE DIR3 B OP Phase directional element operation Group 3 Phase B
PHASE DIR3 BLOCK C Phase directional element block Group 3 Phase C
PHASE DIR3 C OP Phase directional element operation Group 3 Phase C
Neutral Directional
NEUTRAL DIR1 BLK INP Neutral directional element block input signal Group 1
NEUTRAL DIR1 BLOCK Neutral directional element blocked Group 1
NEUTRAL DIR1 OP Neutral directional element operation Group 1
NEUTRAL DIR2 BLK INP Neutral directional element block input signal Group 2
NEUTRAL DIR2 BLOCK Neutral directional element blocked Group 2
NEUTRAL DIR2 OP Neutral directional element operation Group 2
NEUTRAL DIR3 BLK INP Neutral directional element block input signal Group 3
NEUTRAL DIR3 BLOCK Neutral directional element blocked Group 3
NEUTRAL DIR3 OP Neutral directional element operation Group 3
Ground Directional
GROUND DIR1 BLK INP Ground directional element block input signal Group 1
GROUND DIR1 BLOCK Ground directional element blocked Group 1
GROUND DIR1 OP Ground directional element operation Group 1
GROUND DIR2 BLK INP Ground directional element block input signal Group 2
GROUND DIR2 BLOCK Ground directional element blocked Group 2
GROUND DIR2 OP Ground directional element operation Group 2
GROUND DIR3 BLK INP Ground directional element block input signal Group 3
GROUND DIR3 BLOCK Ground directional element blocked Group 3
GROUND DIR3 OP
Ground directional element operation Group 3
OPERANDS - F650 - MODEL FX - GX
Internal System Status
