APPENDIX A: LOGIC OPERANDS A.1 OPERANDS - F650 - MODEL FX - GX
GEK-106310-AF F650 DIGITAL BAY CONTROLLER A-21
Sensitive Ground Directional
SENS GND DIR1 BLK IP
Sensitive ground directional element block input Group
1
SENS GND DIR1 BLOCK Sensitive Ground directional element block Group 1
SENS GND DIR1 OP Sensitive Ground directional element operation Group 1
SENS GND DIR2 BLK IP
Sensitive ground directional element block input Group
2
SENS GND DIR2 BLOCK Sensitive Ground directional element block Group 2
SENS GND DIR2 OP Sensitive Ground directional element operation Group 2
SENS GND DIR3 BLK IP
Sensitive ground directional element block input Group
3
SENS GND DIR3 BLOCK Sensitive Ground directional element block Group 3
SENS GND DIR3 OP Sensitive Ground directional element operation Group 3
Fuse failure VT FUSE FAILURE Fuse failure operation
Phase UV
PHASE UV1 BLOCK Phase undervoltage element block Group 1
PHASE UV1 A PKP Undervoltage element pickup AG Group 1
PHASE UV1 A OP Undervoltage element operation AG Group 1
PHASE UV1 B PKP Undervoltage element pickup BG Group 1
PHASE UV1 B OP Undervoltage element operation BG Group 1
PHASE UV1 C PKP Undervoltage element pickup CG Group 1
PHASE UV1 C OP Undervoltage element operation CG Group 1
PHASE UV1 AB PKP Undervoltage element pickup AB Group 1
PHASE UV1 AB OP Undervoltage element operation AB Group 1
PHASE UV1 BC PKP Undervoltage element pickup BC Group 1
PHASE UV1 BC OP Undervoltage element operation BC Group 1
PHASE UV1 CA PKP
Undervoltage element pickup CA Group 1
