A-24 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
A.1 OPERANDS - F650 - MODEL FX - GX APPENDIX A: LOGIC OPERANDS
Neutral OV Low
NEUTRAL OV1 LOW BLK Neutral overvoltage element block low level Group 1
NEUTRAL OV1 LOW PKP Neutral overvoltage element pickup low level Group 1
NEUTRAL OV1 LOW OP
Neutral overvoltage element operation low level Group
1
NEUTRAL OV2 LOW BLK Neutral overvoltage element block low level Group 2
NEUTRAL OV2 LOW PKP Neutral overvoltage element pickup low level Group 2
NEUTRAL OV2 LOW OP
Neutral overvoltage element operation low level Group
2
NEUTRAL OV3 LOW BLK Neutral overvoltage element block low level Group 3
NEUTRAL OV3 LOW PKP Neutral overvoltage element pickup low level Group 3
NEUTRAL OV3 LOW OP
Neutral overvoltage element operation low level Group
3
Auxiliary UV
AUXILIARY UV1 BLOCK Auxiliary undervoltage element block Group 1
AUXILIARY UV1 PKP Auxiliary undervoltage element pickup Group 1
AUXILIARY UV1 OP Auxiliary undervoltage element operation Group 1
AUXILIARY UV2 BLOCK Auxiliary undervoltage element block Group 2
AUXILIARY UV2 PKP Auxiliary undervoltage element pickup Group 2
AUXILIARY UV2 OP Auxiliary undervoltage element operation Group 2
AUXILIARY UV3 BLOCK Auxiliary undervoltage element block Group 3
AUXILIARY UV3 PKP Auxiliary undervoltage element pickup Group 3
AUXILIARY UV3 OP Auxiliary undervoltage element operation Group 3
Auxiliary OV
AUXILIARY OV1 BLOCK Auxiliary overvoltage element block Group 1
AUXILIARY OV1 PKP Auxiliary Overvoltage element pickup Group 1
AUXILIARY OV1 OP Auxiliary overvoltage element operation Group 1
AUXILIARY OV2 BLOCK Auxiliary overvoltage element block Group 2
AUXILIARY OV2 PKP Auxiliary Overvoltage element pickup Group 2
AUXILIARY OV2 OP Auxiliary overvoltage element operation Group 2
AUXILIARY OV3 BLOCK Auxiliary overvoltage element block Group 3
AUXILIARY OV3 PKP Auxiliary Overvoltage element pickup Group 3
AUXILIARY OV3 OP Auxiliary overvoltage element operation Group 3
Negative Sequence OV
NEG SEQ OV1 BLOCK Negative sequence overvoltage element block Group 1
NEG SEQ OV1 PKP Negative sequence overvoltage element pickup Group 1
NEG SEQ OV1 OP
Negative sequence overvoltage element operation
Gr
oup 1
NEG SEQ OV2 BLOCK Negative sequence overvoltage element block Group 2
NEG SEQ OV2 PKP Negative sequence overvoltage element pickup Group 2
NEG SEQ OV2 OP
Negative sequence overvoltage element operation
Gr
oup 2
NEG SEQ OV3 BLOCK Negative sequence overvoltage element block Group 3
NEG SEQ OV3 PKP Negative sequence overvoltage element pickup Group 3
NEG SEQ OV3 OP
Negative sequence overvoltage element operation
Group 3
OPERANDS - F650 - MODEL FX - GX
Internal System Status
To Next Page
