APPENDIX A: LOGIC OPERANDS A.1 OPERANDS - F650 - MODEL FX - GX
GEK-106310-AF F650 DIGITAL BAY CONTROLLER A-29
Load Encroachment
LOAD ENCR1 BLK Load Encroachment element block Group 1
LOAD ENCR1 PKP Load Encroachment element pickup Group 1
LOAD ENCR1 OP Load Encroachment element operation Group 1
LOAD ENCR2 BLK Load Encroachment element block Group 2
LOAD ENCR2 PKP Load Encroachment element pickup Group 2
LOAD ENCR2 OP Load Encroachment element operation Group 2
LOAD ENCR3 BLK Load Encroachment element block Group 3
LOAD ENCR3 PKP Load Encroachment element pickup Group 3
LOAD ENCR3 OP Load Encroachment element operation Group 3
wattmetric Ground Fault High (Logic Operands)
32N1 HIGH BLOCK wattmetric Ground Fault Element Block High Level
Gr
oup 1
32N1 HIGH PKP wattmetric Ground Fault Element Global Pickup
(cur
rent, voltage and power) High Level Group 1
32N1 HIGH OC PKP wattmetric Ground Fault Element Overcurrent Pickup
High Level Gr
oup 1
32N1 HIGH OP wattmetric Ground Fault Element Operation High Level
Gr
oup 1
32N2 HIGH BLOCK wattmetric Ground Fault Element Block High Level
Gr
oup 2
32N2 HIGH PKP wattmetric Ground Fault Element Global Pickup
(cur
rent, voltage and power) High Level Group 2
32N2 HIGH OC PKP wattmetric Ground Fault Element Overcurrent Pickup
High Level Gr
oup 2
32N2 HIGH OP wattmetric Ground Fault Element Operation High Level
Gr
oup 2
32N3 HIGH BLOCK wattmetric Ground Fault Element Block High Level
Gr
oup 3
32N3 HIGH PKP wattmetric Ground Fault Element Global Pickup
(cur
rent, voltage and power) High Level Group 3
32N3 HIGH OC PKP wattmetric Ground Fault Element Overcurrent Pickup
High Level Gr
oup 3
32N3 HIGH OP wattmetric Ground Fault Element Operation High Level
Gr
oup 3
wattmetric Ground Fault High (Power
Mea
surements)
32N1 HIGH POWER wattmetric Ground Fault Element High Level Group 1
Po
wer Value (watts)
32N2 HIGH POWER wattmetric Ground Fault Element High Level Group 2
Po
wer Value (watts)
32N3 HIGH POWER
wattmetric Ground Fault Element High Level Group 3
Power Value (watts)
OPERANDS - F650 - MODEL FX - GX
Internal System Status
