A-30 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
A.1 OPERANDS - F650 - MODEL FX - GX APPENDIX A: LOGIC OPERANDS
wattmetric Ground Fault Low (Logic Operands)
32N1 LOW BLOCK wattmetric Ground Fault Element Block Low Level
Gr
oup 1
32N1 LOW PKP wattmetric Ground Fault Element Global Pickup
(cur
rent, voltage and power) Low Level Group 1
32N1 LOW OC PKP wattmetric Ground Fault Element Overcurrent Pickup
Low Level Gr
oup 1
32N1 LOW OP wattmetric Ground Fault Element Operation Low Level
Gr
oup 1
32N2 LOW BLOCK wattmetric Ground Fault Element Block Low Level
Gr
oup 2
32N2 LOW PKP wattmetric Ground Fault Element Global Pickup
(cur
rent, voltage and power) Low Level Group 2
32N2 LOW OC PKP wattmetric Ground Fault Element Overcurrent Pickup
Low Level Gr
oup 2
32N2 LOW OP wattmetric Ground Fault Element Operation Low Level
Gr
oup 2
32N3 LOW BLOCK wattmetric Ground Fault Element Block Low Level
Gr
oup 3
32N3 LOW PKP wattmetric Ground Fault Element Global Pickup
(cur
rent, voltage and power) Low Level Group 3
32N3 LOW OC PKP wattmetric Ground Fault Element Overcurrent Pickup
Low Level Gr
oup 3
32N3 LOW OP wattmetric Ground Fault Element Operation Low Level
Gr
oup 3
wattmetric Ground Fault Low (Power
Mea
surements)
32N1 LOW POWER wattmetric Ground Fault Element Low Level Group 1
Po
wer Value (watts)
32N2 LOW POWER wattmetric Ground Fault Element Low Level Group 2
Po
wer Value (watts)
32N3 LOW POWER wattmetric Ground Fault Element Low Level Group 3
Po
wer Value (watts)
Remote Outputs
DNA 1
1 output on. Remote Output DNA 1 Operation (GSSE/
G
OOSE)
DNA 2
1 output on. Remote Output DNA 2 Operation (GSSE/
G
OOSE)
... ...
DNA 32
1 output on. Remote Output DNA 32 Operation (GSSE/
G
OOSE)
User St 1
1 output on. Remote Output UserSt 1 Operation (GSSE/
G
OOSE)
User St 2
1 output on. Remote Output UserSt 2 Operation (GSSE/
G
OOSE)
... ...
User St 64
1 output on. Remote Output UserSt 64 Operation (GSSE/
G
OOSE)
Rem GOOSE Dig Out 1
1 output on. Remote Output GOOSE 1 Operation
(G
OOSE)
Rem GOOSE Dig Out 2
1 output on. Remote Output GOOSE 2 Operation
(G
OOSE)
... ...
Rem GOOSE Dig Out 32
1 output on. Remote Output GOOSE 32 Operation
(GOOSE)
OPERANDS - F650 - MODEL FX - GX
Internal System Status
To Next Page
